Project Overview
Comprehensive 3D modeling and shop drawing generation for commercial and industrial steel structures generated directly in Tekla Structures, compliant with AISC (US) and Eurocode 3 (EN 1993 / EU) structural standards.
Stack & Execution
Built detailed 3D steel frames in Tekla Structures, incorporating connections, bolts, welds, and anchor bolts. Generated automated erection drawings, shop assembly sheets, and bill of materials (BOM/NC files) for US and European steel fabricators.
Role & Contribution
Complete KMD / Shop Drawing drafting and 3D Tekla modeling. Guaranteed 100% constructability and zero clash errors between structural steel components and real site erection.
Let’s Work Together
Ready to Scale Your Drafting Capacity?
Send us your drawings, point clouds, or sketches. We will deliver a free sample draft or a fixed project quote within 2 hours.
